Query Vision Language Model

Querying Qwen-VL

import nest_asyncio

nest_asyncio.apply()  # Run this first.

model_path = "Qwen/Qwen2.5-VL-3B-Instruct"
chat_template = "qwen2-vl"

# Lets create a prompt.

from io import BytesIO
import requests
from PIL import Image

from sglang.srt.parser.conversation import chat_templates

image = Image.open(
    BytesIO(
        requests.get(
            "https://github.com/sgl-project/sglang/blob/main/test/lang/example_image.png?raw=true"
        ).content
    )
)

conv = chat_templates[chat_template].copy()
conv.append_message(conv.roles[0], f"What's shown here: {conv.image_token}?")
conv.append_message(conv.roles[1], "")
conv.image_data = [image]

print(conv.get_prompt())

/usr/local/lib/python3.10/dist-packages/torch/cuda/__init__.py:63: FutureWarning: The pynvml package is deprecated. Please install nvidia-ml-py instead. If you did not install pynvml directly, please report this to the maintainers of the package that installed pynvml for you.
  import pynvml  # type: ignore[import]

<|im_start|>system
You are a helpful assistant.<|im_end|>
<|im_start|>user
What's shown here: <|vision_start|><|image_pad|><|vision_end|>?<|im_end|>
<|im_start|>assistant

Query via the offline Engine API

from sglang import Engine

llm = Engine(
    model_path=model_path, chat_template=chat_template, mem_fraction_static=0.8
)

All deep_gemm operations loaded successfully!

`torch_dtype` is deprecated! Use `dtype` instead!
[2025-09-28 18:30:33] `torch_dtype` is deprecated! Use `dtype` instead!
/usr/local/lib/python3.10/dist-packages/torch/cuda/__init__.py:63: FutureWarning: The pynvml package is deprecated. Please install nvidia-ml-py instead. If you did not install pynvml directly, please report this to the maintainers of the package that installed pynvml for you.
  import pynvml  # type: ignore[import]
/usr/local/lib/python3.10/dist-packages/torch/cuda/__init__.py:63: FutureWarning: The pynvml package is deprecated. Please install nvidia-ml-py instead. If you did not install pynvml directly, please report this to the maintainers of the package that installed pynvml for you.
  import pynvml  # type: ignore[import]
`torch_dtype` is deprecated! Use `dtype` instead!
[2025-09-28 18:30:42] `torch_dtype` is deprecated! Use `dtype` instead!

[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
[Gloo] Rank 0 is connected to 0 peer ranks. Expected number of connected peer ranks is : 0
All deep_gemm operations loaded successfully!

Loading safetensors checkpoint shards:   0% Completed | 0/2 [00:00<?, ?it/s]
Loading safetensors checkpoint shards:  50% Completed | 1/2 [00:00<00:00,  1.15it/s]
Loading safetensors checkpoint shards: 100% Completed | 2/2 [00:01<00:00,  1.24it/s]
Loading safetensors checkpoint shards: 100% Completed | 2/2 [00:01<00:00,  1.22it/s]

Capturing batches (bs=1 avail_mem=4.64 GB): 100%|██████████| 36/36 [00:42<00:00,  1.17s/it]

out = llm.generate(prompt=conv.get_prompt(), image_data=[image])
print(out["text"])

I'm not sure what specifically is shown in the image, but it appears to be anUrban scene, with buildings, streetlights, cars, and people.

Query via the offline Engine API, but send precomputed embeddings

# Compute the image embeddings using Huggingface.

from transformers import AutoProcessor
from transformers import Qwen2_5_VLForConditionalGeneration

processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
vision = (
    Qwen2_5_VLForConditionalGeneration.from_pretrained(model_path).eval().visual.cuda()
)

processed_prompt = processor(
    images=[image], text=conv.get_prompt(), return_tensors="pt"
)
input_ids = processed_prompt["input_ids"][0].detach().cpu().tolist()
precomputed_embeddings = vision(
    processed_prompt["pixel_values"].cuda(), processed_prompt["image_grid_thw"].cuda()
)

mm_item = dict(
    modality="IMAGE",
    image_grid_thw=processed_prompt["image_grid_thw"],
    precomputed_embeddings=precomputed_embeddings,
)
out = llm.generate(input_ids=input_ids, image_data=[mm_item])
print(out["text"])

The image shows a vehicle with two rearview mirrors raised off the ground, attached to its rear side, as if it's been shoveling snow. The vehicle is visually recognizable as a taxi from its distinctive bright yellow color and five-pointed star logo. This makes the gradient effect utilized in this situation more impactful and attention-grabbing because the long, curved mirrors are not standard on cars in urban areas, especially in busy streets like those in New York City, where frequent snow clearing is necessary.

The image conveys humor by presenting an unexpected and impractical scene of a vehicle performing a snow-removal task. This exaggeration

Querying Llama 4 (Vision)

import nest_asyncio

nest_asyncio.apply()  # Run this first.

model_path = "meta-llama/Llama-4-Scout-17B-16E-Instruct"
chat_template = "llama-4"

# Lets create a prompt.

from io import BytesIO
import requests
from PIL import Image

from sglang.srt.parser.conversation import chat_templates

image = Image.open(
    BytesIO(
        requests.get(
            "https://github.com/sgl-project/sglang/blob/main/test/lang/example_image.png?raw=true"
        ).content
    )
)

conv = chat_templates[chat_template].copy()
conv.append_message(conv.roles[0], f"What's shown here: {conv.image_token}?")
conv.append_message(conv.roles[1], "")
conv.image_data = [image]

print(conv.get_prompt())
print(f"Image size: {image.size}")


<|header_start|>user<|header_end|>

What's shown here: <|image|>?<|eot|><|header_start|>assistant<|header_end|>


Image size: (570, 380)

Query via the offline Engine API

from sglang.test.test_utils import is_in_ci

if not is_in_ci():
    from sglang import Engine

    llm = Engine(
        model_path=model_path,
        trust_remote_code=True,
        enable_multimodal=True,
        mem_fraction_static=0.8,
        tp_size=4,
        attention_backend="fa3",
        context_length=65536,
    )

if not is_in_ci():
    out = llm.generate(prompt=conv.get_prompt(), image_data=[image])
    print(out["text"])

Query via the offline Engine API, but send precomputed embeddings

if not is_in_ci():
    # Compute the image embeddings using Huggingface.

    from transformers import AutoProcessor
    from transformers import Llama4ForConditionalGeneration

    processor = AutoProcessor.from_pretrained(model_path, use_fast=True)
    model = Llama4ForConditionalGeneration.from_pretrained(
        model_path, torch_dtype="auto"
    ).eval()
    vision = model.vision_model.cuda()
    multi_modal_projector = model.multi_modal_projector.cuda()

if not is_in_ci():
    processed_prompt = processor(
        images=[image], text=conv.get_prompt(), return_tensors="pt"
    )
    print(f'{processed_prompt["pixel_values"].shape=}')
    input_ids = processed_prompt["input_ids"][0].detach().cpu().tolist()

    image_outputs = vision(
        processed_prompt["pixel_values"].to("cuda"), output_hidden_states=False
    )
    image_features = image_outputs.last_hidden_state
    vision_flat = image_features.view(-1, image_features.size(-1))
    precomputed_embeddings = multi_modal_projector(vision_flat)

    mm_item = dict(modality="IMAGE", precomputed_embeddings=precomputed_embeddings)
    out = llm.generate(input_ids=input_ids, image_data=[mm_item])
    print(out["text"])
